‹ Back to blog

Web Development

Getting Started with Mitosis: Creating a Cross-Framework Design System

May 7, 2024

Written By Vishwas Gopinath

Imagine if you, as a maintainer of design systems, could cater to different web frameworks without any extra effort or repetition in managing libraries.

Imagine if your team could seamlessly align design systems for a consistent user experience across various platforms, no matter the web frameworks you use.

Imagine if your business could fundamentally transform the way your engineering teams operate, making your development processes more efficient and effective.

At Builder.io, we've developed Mitosis — a solution to create a single source of truth for all reusable components within your design system. This blog post will guide you through getting started with Mitosis and how it can streamline the management of multi-framework environments.

What is Mitosis?

Mitosis is an open-source tool that transforms JSX components into fully functional components for frameworks like Angular, React, Qwik, Vue, Svelte, Solid, and React Native. By writing your UI components once in JSX, you can deploy them across any platform, eliminating the need to rewrite code for each framework.

This promotes consistent component design and enhances productivity, maintaining uniformity throughout your development process.

Explore it yourself with the Mitosis fiddle.

With Mitosis, you can streamline your workflow and reduce redundancy without compromising the quality of your design system. Mitosis ensures that your design language speaks clearly and consistently, whether you're working in React, Vue, or any other framework.

By simplifying the development process, Mitosis accelerates project timelines, allowing your team to focus more on innovation and less on integration.

While web components are standalone elements designed for reuse across web applications, they present some key challenges for design systems:

  • Web components do not natively render on the server side. This can be problematic when using frameworks that rely on server-side rendering for performance and SEO benefits.
  • Web components do not seamlessly integrate with your library or framework. For instance, web components do not inherently understand or interact with React's context.
  • Web components often come with their own rendering libraries and dependencies, which can lead to performance overhead.

Although web components offer a modular and reusable approach to UI elements, these challenges can limit their viability. However, if supporting web components is a requirement, you can use Mitosis to generate them from a single source of truth. Mitosis supports Stencil, Lit, and raw web components as outputs.

Start a new Mitosis project by running the following command in your terminal:

npm create @builder.io/mitosis@latest

When prompted, enter a project name and select your desired output. Currently, we support outputs for React, Svelte, and Qwik.

After making your selection, navigate to the project folder and install the dependencies.

cd <project-folder>
npm install

Focus on the library folder within your project. In library/src, you will find:

  • An autocomplete component
  • A todo-app component

Each component is housed in its own folder and written in a .lite.tsx file, the standard file format for Mitosis components. Also, explore the library/packages folder, which contains starter code for the outputs you selected during setup.

1. Start the development server

From within the library folder, run the following command to start the development server:

npm run start

This command automatically generates component code in the corresponding output folder. You write code once, and it gets converted into React, Qwik, and Svelte code.

2. Add a new component

Create a library/src/greet.lite.tsx file with the following code:

import { useStore } from "@builder.io/mitosis";

export default function Greet() {
  const state = useStore({
    name: "",
  });

  return (
    <div>
      <input
        value={state.name}
        onChange={(e) => state.name = e.target.value}
        placeholder="Your name"
      />
      <div>Hello, {state.name}!</div>
    </div>
  );
}

Saving the file triggers the automatic conversion of the Mitosis component into target components. Here is an example showing how a simple component is automatically translated from Mitosis to Svelte and React:

Here’s the Svelte component code:

<script lang="ts">
  let name = "";
</script>

<div>
  <input placeholder="Your name" bind:value={name} />
  <div>Hello, {name}!</div>
</div>

And here’s the React component code:

"use client";
import * as React from "react";
import { useState } from "react";

function Greet(props: any) {
  const [name, setName] = useState(() => "");

  return (
    <div>
      <input
        placeholder="Your name"
        value={name}
        onChange={(e) => setName(e.target.value)}
      />
      <div>Hello, {name}!</div>
    </div>
  );
}

export default Greet;

3. Configure project settings

In the root of your project, add a mitosis.config.js file to specify the target output. Possible targets include Alpine, Angular, customElement, HTML, Mitosis, Liquid, React, React Native, Solid, Svelte, Swift, Template, Webcomponent, Vue (version 3), Stencil, Qwik, Marko, Preact, Lit, and RSC.

Here's the Vue component code if you were to configure Vue as a target:

<template>
  <div>
    <input
      placeholder="Your name"
      :value="name"
      @change="name = $event.target.value"
    />
    <div>Hello, {{ name }}!</div>
  </div>
</template>

<script setup lang="ts">
import { ref } from "vue";

const name = ref("");
</script>

After generating the component code with Mitosis, the next step is to ensure that your components work as expected. Here's how to verify them using Svelte as the target framework:

1. Export the components

Export the Greet component from the library/src/index.ts file:

export { default as Greet } from "./greet/greet.lite"

2. Build the library

From the library/packages/svelte folder, build the Svelte components by running the following command:

npm run build:watch

3. Test in a Svelte application

Navigate to the test-apps/svelte folder:

cd test-apps/svelte

Open the src/routes/+page.svelte file and import the component:

<script lang="ts">
  import { AutoComplete, Todos, Greet } from '@demo-one/library-svelte';
</script>

<h1>Welcome to SvelteKit</h1>
<AutoComplete />
<Todos />
<Greet />
<p>Visit <a href="https://kit.svelte.dev">kit.svelte.dev</a> to read the documentation</p>

4. Start the dev server

Start the development server for your Svelte app with the following command:

npm run dev

5. Verify the component

Open http://localhost:5173 in your browser. You should see the functioning Greet component along with the other components.

By following these steps, you'll be well on your way to developing with Mitosis, taking advantage of its capability to write once and deploy to multiple frameworks.

You can leverage Mitosis in conjunction with Visual Copilot to efficiently translate Figma designs into code.

Visual Copilot is an AI-powered Figma to code toolchain that leverages AI to swiftly and accurately convert Figma designs to clean and responsive code.

To use this integration:

  1. In Figma, select the layer you wish to convert and use the Visual Copilot plugin.
  2. Click the Generate Code button to start the conversion.
  3. Set Mitosis as the target framework for the generated code.
  4. Copy the code and paste it into a file within the library/src directory of your Mitosis project. For example, library/src/login/login.tsx. Mitosis will then automatically adapt this code to your selected frameworks, maintaining a consistent design system across multiple platforms.

This method ensures that developers can work within a unified framework while supporting various technology stacks.

Mitosis enables developers to maintain a consistent design system across various web frameworks. By allowing you to write your UI components once and deploy them on multiple platforms, Mitosis enhances productivity and ensures a uniform user experience. When used with Visual Copilot, you can seamlessly translate Figma designs into precise, functional code that can easily be maintained across frameworks.

For further learning, refer to the Mitosis documentation and learn about Visual Copilot: Figma to code with AI.
